12V 50AH Lithium Ion Battery

Model #: 12V50AH SKU: 796762840892 Weight: 15 lbs

Product Details

COMMERCIAL

MARINE

UPS

RV

AUTOMOTIVE

 This 12V 50AH Lithium Ion Battery features an automatic built in battery protection system (BPS) that keeps the battery running at peak performance and protects the cells for thousands of cycles. Designed to be plug and play for any application that currently uses a lead acid, gel or agm battery.

---

POWER & ENERGY

THE ELECTRIC ADVANTAGE

Nominal Voltage	12.8V
Charge Voltage	14.4V - 14.6V
Peak Discharge (5 Sec)	500A
Continuous Charge / Discharge Rate	50A
Capacity (amp hours)	50AH
Capacity (watt hours)	600WH

SIZE & WEIGHT
ADVANTAGE

Model	12V50AH
Group Size	12V50A
Weight	15 Lbs
Length	7.7"
Width	6.45"
Height	6.75"

TECHNOLOGY
ADVANTAGE

Usable Capacity (AH)	50AH
Depth of Discharge	100% DOD
Reserve Minutes @ 20A	150 min
Self Discharge	<3% per mo
Chemistry	Lithium Iron Phosphate (LiFePO4)
Cell Type	Cylindrical
Modular	Series or Parallel Connection

SAFETY & PROTECTION
ADVANTAGE

Built in Automatic Battery Protection System	Internal
Automatic Low Voltage Disconnect	8V
Automatic Short Circuit Protection	Instant
Automatic Over Voltage Protection	15.8V
Automatic Reverse Polarity Protection	Instant
Internal Cell Thermal Safety Fuse	Yes
Flame Retardant Electrolyte	Yes
Length Way Circuit Boards	Yes
Automatic Internal Cell Balancing	Yes
Automatic Fault Recovery	Yes
Explosion Proof Stainless Steel Cells	Yes

TEMPERATURE PERFORMANCE
ADVANTAGE

Celsius	Fahrenheit	Usable Capacity
60	140	103%
50	122	102%
40	104	100%
30	86	100%
20	68	98%
10	50	92%
0	32	83%
-10	14	80%
-20	-4	70%
-30	-22	60%
-40	-40	10%
-50	-58	0%



FAST SHIPPING
ADVANTAGE

Standard Shipping	UPS GROUND
Expedited Air Shipping	UPS WORLDWIDE EXPRESS
Shipping Time	Ships within 24 hours

LIFETIME WARRANTY
ADVANTAGE

Repair or Replace	First 5 Years
Repair or Pro Rate	Life Time
Detailed Warranty Information	Warranty

This Product Is Perfect For

Motorhomes, Travel Trailers, Fifth Wheels, Boats, Yachts, Sailing, Trolling Motors, Electronics, Solar Backup Power, and Other Deep Cycle Applications.

Thisy 12V 50AH Lithium Ion Battery is the perfect replacement from a AGM, GEL or Lead Acid Battery. Designed as a "drop in replacement" meaning all you have to do is take out your old battery and place the lithium battery in the same way.
