48V 50AH Lithium Ion Battery

Model #: CX48508D SKU: 48-LIB-50-8D Weight: 90 lbs

Quantity

Product Details

The Chargex® 48V 50AH Lithium Ion Battery features the latest and most advanced Lithium Iron Phosphate - LiFePO4 Battery Technology.


Designed for Marine & RV applications, the CX48508D is engineered to handle extreme vibration and is Plug and Play for any application that currently uses lead acid, gel or agm batteries. Our High Output 3.2V Stainless Steel LiFePO4 Cells are bolted together for Rigid Strength and Current Conductivity vs. the tab welded method.


The fully automatic Built In Battery Management System provides cell balancing, over charge or over discharge protection, short circuit and reverse polarity protection all making the Chargex CX48508D, one of the world's safest and most advanced lithium batteries.


The Chargex® CX48508D comes with the industries leading - Lifetime Warranty.


12V 300AH Lithium Battery Data SheetCX48508D - 48V Lithium Ion Battery Data Sheet

MSDS-Sheet-Download-Button.pngLiFePO4 - Material Safety Data Sheet  (MSDS)



POWER & ENERGY

THE ELECTRIC ADVANTAGE

Nominal Voltage 51.2V (48V)
Charge Voltage 57.6V - 58.4V
Cold Cranking Amps / Peak Discharge (5 Sec) 500A
Continuous Charge / Discharge Rate 50A
Capacity (amp hours) 50AH
Capacity (watt hours) 2560WH


SIZE & WEIGHT
ADVANTAGE

Model CX48508D
Group Size 8D
Weight 88 Lbs
Length 20.5"
Width 10.25"
Height 8.75"


TECHNOLOGY
ADVANTAGE

Usable Capacity (AH) 50AH
Depth of Discharge 100% DOD
Reserve Minutes @ 10A 300 min
Self Discharge <1% per mo
Chemistry Lithium Iron Phosphate (LiFePO4)
Cell Type Cylindrical
Modular Series or Parallel Connection



SAFETY & PROTECTION
ADVANTAGE

Built in Automatic Battery Protection System        Internal
Automatic Low Voltage Disconnect 32V
Automatic Short Circuit Protection Instant
Automatic Over Voltage Protection 63.2V
Automatic Reverse Polarity Protection Instant
Internal Cell Thermal Safety Fuse Yes
Flame Retardant Electrolyte Yes
Length Way Circuit Boards Yes
Automatic Internal Cell Balancing Yes
Automatic Fault Recovery Yes
Explosion Proof Stainless Steel Cells Yes



TEMPERATURE PERFORMANCE
ADVANTAGE

Celsius Fahrenheit  Usable Capacity
60 140 103%
50 122 102%
40 104 100%
30 86 100%
20 68 98%
10 50 92%
0 32 83%
-10 14 80%
-20 -4 70%
-30 -22 60%
-40 -40 10%
-50 -58 0%



FAST SHIPPING
ADVANTAGE

Standard Shipping UPS GROUND
Expedited Air Shipping UPS WORLDWIDE EXPRESS
Shipping Time Call for availability


STAINLESS STEEL BOLTED CELLS FOR SUPERIOR STRENGTH
Stainless Steel Bolted Cells
Explosion Proof
BOLTED BMS



LENGTHWAY CIRCUIT BOARDS
Rigid Strength
Cell Balancing
Short Circuit Protection



BUILT IN FULLY AUTOMATIC HEAVY DUTY BMS / BPS
Over Voltage Protection
Low Voltage Protection
Short Circuit Protection
Reverse Polarity Protection
Automatic Cell Balancing



3.2V 5.5AH CHARGEX® STAINLESS STEEL LITHIUM IRON PHOSPHATE BATTERY CELL
Explosion Proof Stainless Steel
High Pressure Safety Vent
Flame Retardant Electrolyte Additive
Bolted for Superior Strength and Conductivity
Safe - LiFePO4 Lithium Iron Phosphate Chemistry
